Name: sbgis.DBO.Sidewalk_Obstructions

Display Field: STREETNAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="margin:0 0 7 0;"><SPAN>Point features locating </SPAN><SPAN>objects </SPAN><SPAN>on sidewalks</SPAN><SPAN>that are considered obstructing the walking paths</SPAN><SPAN>. </SPAN><SPAN>Obstructions </SPAN><SPAN>are </SPAN><SPAN>comparatively small </SPAN><SPAN>built environment features that </SPAN><SPAN>occupy space on </SPAN><SPAN>the sidewalk plane </SPAN><SPAN>so much so to a point that they could be considered to reduce the width of the path of travel. </SPAN><SPAN>The dataset identifies </SPAN><SPAN>obstructions </SPAN><SPAN>based on those defined by </SPAN><SPAN><SPAN>by </SPAN></SPAN><SPAN><SPAN>engineering design standards </SPAN></SPAN><SPAN><SPAN>as of April 2019.</SPAN></SPAN><SPAN>The dataset extent covers all 25 jurisdictions in the County, though each jurisdiction is limited to having ramps identified with a specific 1/2 mile or 1/4 mile Euclidian radius of prominent pedestrian sites as defined during the Sidewalk Inventory Plan. For further details regarding the methodology</SPAN><SPAN /><SPAN><SPAN>and typologies used to obstruction types</SPAN></SPAN><SPAN>, please refer to those plan documents. </SPAN></P><P STYLE="margin:0 0 7 0;"><SPAN>The dataset consists of </SPAN><SPAN>8</SPAN><SPAN>attributes, including:</SPAN></P><UL><LI><P><SPAN>'</SPAN><SPAN>Obstruction</SPAN><SPAN>Type': Defines the type of </SPAN><SPAN>obstruction</SPAN><SPAN>.</SPAN></P></LI><LI><P><SPAN>'</SPAN><SPAN>StationaryObstruction</SPAN><SPAN>': Identifies in binary terms if the </SPAN><SPAN>object is </SPAN><SPAN><SPAN>perceived</SPAN></SPAN><SPAN>to be mobile or fixed to its location</SPAN><SPAN>.</SPAN></P></LI><LI><P><SPAN>'StreetName': Identifies the closest street that the object is near.</SPAN></P></LI></UL><P STYLE="margin:0 0 7 0;"><SPAN>The attributes also contains a 'Notes' field for each record for additional observations on each record to be included should there be more notes. The majority if not all of these entries will most likely be 'null'.</SPAN></P></DIV></DIV></DIV>

Copyright Text: SBCTA, David Evans and Associates

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6637157.832953892
YMin: 1814132.1128284791
XMax: 7581400.765974611
YMax: 2150382.554809787
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [139, 150, 43, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• STATIONARYOBSTRUCTION ( type: esriFieldTypeString, alias: STATIONARYOBSTRUCTION, length: 100 , Coded Values: [0: No] , [1: Yes] , [2: Unknown] )
• OBSTRUCTIONTYPE ( type: esriFieldTypeString, alias: OBSTRUCTIONTYPE, length: 100 , Coded Values: [0: Trees] , [1: Utility Wire] , [2: Raised Vent] , ...26 more... )
• JURISDICTION ( type: esriFieldTypeString, alias: JURISDICTION, length: 50 , Coded Values: [0: Adelanto] , [1: Apple Valley] , [10: Chino Hills] , ...61 more... )
• SOURCEGEO ( type: esriFieldTypeString, alias: SOURCEGEO, length: 50 , Coded Values: [0: SBCTA Aerial] , [1: Jurisdiction Aerial] , [2: Google Street View] , ...3 more... )
• SOURCEGEODATE ( type: esriFieldTypeInteger, alias: SOURCEGEODATE , Coded Values: [0: 2019] , [1: 2018] , [2: 2017] , ...8 more... )
• SOURCEATTR ( type: esriFieldTypeString, alias: SOURCEATTR, length: 50 , Coded Values: [0: DEA] , [1: SBCTA] , [2: Jurisdiction] )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 250 )
• STREETNAME ( type: esriFieldTypeString, alias: STREETNAME, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
